Ölwechsel Set 5L 5W30 Öl Motoröl CASTROL + MANN Ölfilter + Ablassschraube
(A9100001MANNC)
Item No.: WW343524

Item No.:: WW343524
Manufacturer:: MANN-FILTER
Manufacturer-Number:: A9100001MANNC
EAN-Code:: 4057311049859

Oil Filter

MANN-FILTER W 712/52
Outer diameter [mm]: 76
Inner diameter 1 [mm]: 62
Inner diameter 2 [mm]: 71
Thread Size: 3/4-16 UNF
Height [mm]: 92
Bypass Valve Opening Pressure [bar]: 2,5
Supplementary Article/Info 2: with one anti-return valve

Engine Oil

CASTROL EDGE LL 5W-30 15669E
Capacity [Litre]: 5
Packing Type: Canister
Oil Viscosity Classification SAE: 5W-30
Specification: ACEA C3
Manufacturer Release: MB 229.31/229.51, VW 504 00/507 00, Porsche C30

Sealing Plug, oil sump

FEBI BILSTEIN 15374
Length [mm]: 29,5
Outer thread [mm]: M14 x 1,5
Spanner Size: 19
Bolt Head-/Nut Design: Male Hex
Material: Steel
Surface: Zinc-coated
Screw length below head [mm]: 22
Supplementary Article/Info 2: with seal
Weight [kg]: 0,04
Observe service information

Height [mm]:: 92
Length [mm]:: 29,5
Spanner Size:: 19
Thread Size:: 3/4-16 UNF
Surface:: Zinc-coated
Material:: Steel
Bolt Head-/Nut Design:: Male Hex
Content [litre]:: 5
Packing Type:: Canister
Quantity:: 5 L
Inner Diameter 2 [mm]:: 71
Inner Diameter 1 [mm]:: 62
Bypass Valve Opening Pressure [bar]:: 2,5
Manufacturer Approval:: MB 229.31, VW 504 00, Porsche C30, MB 229.51, VW 507 00, ACEA C3
Oil Viscosity Classification SAE:: 5W-30
Specification:: ACEA C3
Supplementary Article/Info 2:: with one anti-return valve, with seal
Screw length below head [mm]:: 22
additionalarticlenumber:: W712/52
Outer Diameter [mm]:: 76,00
External Thread [mm]:: M14 x 1,5
manufacturer:: LOTT Set

manufacturer	model	type	power	capacity	constr. date	kba	limitations

OE numbers

AUDI N 908 132 01, AUDI N 908 132 02, CHRYSLER 68004313AA, MITSUBISHI MN980017, MITSUBISHI MN980254, SEAT N 908 132 01, SEAT N 908 132 02, SKODA N 908 132 02, VAG 030 115 561 AA, VAG 030 115 561 AB, VAG 030 115 561 AD, VAG 030 115 561 AN, VAG 030 115 561 E, VAG 030 115 561 F, VAG 030 115 561 K, VAG 030 115 561 L, VAG 030 115 561 P, VW N 908 132 01, VW N 908 132 02
